64696A-AC-9

64696A-9

Simplicity Collection Automatic Roll Paper Towel Dispenser & Waste Receptacle, Battery Operated – SURFACE MOUNTED


Proximity sensing no-touch unit holds and dispenses one 8″ diameter [Ø203] x 8″ wide [203] standard towel roll up to 800 ft. (244m) long and one 8″ wide [203] stub roll up to 4″ diameter [Ø102] and automatically changes over to main roll when finished with stub roll when feed tabs are properly engaged. Waste receptacle has a capacity of 9.9 gallons (37.3 L).

Surface mounted with 9″ stainless steel collar.

Powered by four (4) D-size batteries (not supplied) and operates automatically to activate towel dispensing when hands are placed in sensor zone. At each activation unit feeds out a length of towel selected by owner by setting length, delay and paper saver switches.

BIM Objects

BIM Objects

BIM Objects

BIM Objects

BIM Objects

Technical Data Sheet

Product Specifications

16-1/16″ x 41-1/4″ x 10-1/4″ (408 x 1048 x 261 mm)

American Specialties, Inc. reserves the right to make design changes or to withdraw any design without notice.
